TechnologiesFused Deposition Modelling

FDM 3D Printing

Stratnel provides FDM 3D printing services to engineering customers across India from our manufacturing facility in Bangalore. Fused Deposition Modelling is our most versatile 3D printing technology — capable of producing everything from investment casting patterns in Stratment 102 to high-performance structural parts in ULTEM™ 9085, PA6-CF, PEEK, and Polycarbonate. Ten materials across a wide range of applications.

FDM Material 01
Stratment 102

Proprietary FDM filament developed by Stratnel specifically for investment casting patterns. Optimised for strength, rigidity, wettability, polishability, and inter-layer adhesion — properties that prevent slurry ingress, shell cracking, and excessive residual ash. Parts cast from Stratment 102 patterns achieve a typical surface finish of 3–6 µm Ra on cast surfaces.

PropertyValue
Tensile strength (XY)>62 MPa
Flexural strength (XY)>85 MPa
Tensile modulus (XY)>3.1 GPa
Ash content<0.15% — clean burnout, minimal rejection
Cast surface finish3–6 µm Ra (geometry dependent)
Best forInvestment casting patterns, foundry pattern supply
Fdm Stratment102
FDM Material 02
PLA

Polylactic acid — a biodegradable thermoplastic ideal for low-cost concept models, visual prototypes, and non-functional parts. Fast to print, easy to post-process.

PropertyValue
Tensile strength45 MPa
Tensile modulus3,500 MPa
Glass transition temperature60°C — not suitable for elevated temperature use
Best forConcept models, visual prototypes, non-structural parts
ColourMultiple colours available
Fdm Pla
FDM Material 03
ABS

Acrylonitrile Butadiene Styrene — a widely used engineering thermoplastic with good impact resistance and machinability. Suitable for functional prototypes and enclosures.

PropertyValue
Tensile strength~51 MPa
Flexural strength~74 MPa
Heat deflection temperature92–96°C (annealed)
Best forFunctional prototypes, enclosures, snap-fit parts
Post-processingAcetone-smoothable for improved surface finish
Fdm Abs
FDM Material 04
PETG

Polyethylene Terephthalate Glycol — combines good mechanical properties with excellent chemical resistance and toughness. Notable for very high elongation at break, making it resilient under impact and flex loading.

PropertyValue
Tensile strength (yield)57 MPa
Flexural strength80 MPa
Elongation at break120% — excellent toughness
Izod impact (notched)Not breaking
Heat deflection temperature63°C (unannealed, 1.80 MPa)
Best forChemical-resistant parts, functional prototypes
Fdm Petg
FDM Material 05
Polycarbonate

High-impact engineering thermoplastic with excellent temperature resistance and optical clarity. Suitable for demanding structural and functional applications.

PropertyValue
Tensile strength62 MPa
Flexural strength78 MPa
Glass transition temperature147°C
Deflection temperature135°C (at 0.45 MPa)
Best forStructural components, impact-resistant housings, and high-load mechanical parts requiring exceptional thermal stability
NoteRequires high-temperature printer — we use Intamsys platform
Fdm Pc
FDM Material 06
Ultem™ 9085

Stratnel manufactures FDM parts in ULTEM™ 9085 for customers across India from our Bangalore facility. ULTEM 9085 is a high-performance PEI engineering thermoplastic with an exceptional strength-to-weight ratio, thermal stability and FST (flame, smoke and toxicity) performance. Widely specified in aerospace, transportation, and medical applications.

PropertyValue
Tensile strength86 MPa
Bending strength116 MPa
Impact strength115 J/m (notched Izod)
Operating temperature-50°C to +150°C
Glass transition temperature186°C
CertificationsUL94 V-0 flame retardant — FST rated for aerospace and transportation
Best forAerospace components, lightweighting, high-temperature, and structural applications
Fdm Ultem9085
FDM Material 07
FR-PC-ABS

Flame-retardant Polycarbonate-ABS blend. Combines the toughness of PC with the processability of ABS and adds UL94 V-0 flame retardancy. Common in electronic enclosures.

PropertyValue
Tensile strength60 MPa
Flexural strength85 MPa
Glass transition temperature137°C
Deflection temperature125°C (at 0.45 MPa)
CertificationsUL94 V-0 @ 1.5mm — flame retardant
Best forElectronic enclosures, EMS applications, flame-rated housings
Fdm Frpcabs
FDM Material 08
ASA

Acrylonitrile Styrene Acrylate — UV-resistant engineering thermoplastic. Excellent outdoor durability without degradation or colour fading. Direct replacement for ABS in outdoor applications.

PropertyValue
Tensile strength45 MPa
Flexural strength78 MPa
Glass transition temperature105°C
UV resistanceExcellent — no yellowing or degradation
Best forProlonged outdoor exposure, resisting UV degradation, and embrittlement where other engineering plastics fail.
Colour stabilityHigh — retains colour under prolonged UV exposure
Fdm Asa
FDM Material 09
PA6-CF

Stratnel offers PA6-CF FDM 3D printing for high-strength, lightweight engineering parts manufactured at our Bangalore facility and supplied to customers across India. Carbon-fibre-reinforced Nylon 6 — a short-fibre composite that combines engineering nylon's toughness with significantly increased stiffness and dimensional stability versus unfilled nylon, and reduced warping during printing. Trade-off is increased brittleness and pronounced anisotropy between print layers.

PropertyValue
Tensile strength (XY)102 MPa
Flexural strength (XY)151 MPa
Tensile modulus (XY)4.4 GPa
Heat deflection temperature164°C (at 1.8 MPa)
Moisture sensitivityAbsorbs ~2.35% moisture at saturation — dry storage and printing required
Best forHigh-stiffness fixtures, jigs, brackets, and structural components requiring rigidity in dry environments
Fdm Pa6cf
FDM Material 10
PEEK

PolyEtherEtherKetone — the highest-performance material in our FDM range. Semi-crystalline, high strength and stiffness, exceptional heat and chemical resistance, and self-extinguishing without additives. The raw material is rated for food contact and biocompatibility, making it suitable for demanding medical, aerospace, and chemical-processing applications requiring sterilization.

PropertyValue
Tensile strength (XY, annealed)86 MPa
Flexural strength (XY, annealed)147 MPa
Heat deflection temperature144°C (at 1.8 MPa)
Melting point343°C
FlammabilityUL94 V0 — self-extinguishing, no additives required
Food contact & biocompatibility (raw material)Passes FDA 21 CFR 177, EU 2011/10, ISO 10993-5/-10, USP 40 <87>/<88>
Best forHigh-temperature, chemically demanding, or sterilization-required applications — medical devices, aerospace, chemical processing
NoteRequires high-temperature printer — we use Intamsys platform

Detailed material datasheets are available upon request. To receive technical documentation for a specific material, please submit an enquiry with your application details.

Common Questions
Frequently Asked Questions

What is the maximum part size you can produce?▾

Maximum part size depends on the selected manufacturing process and available equipment. For FDM, Stratnel can produce parts up to approximately 1 metre in each dimension, subject to part geometry and machine availability.

Larger components may be divided into sections, printed separately, and assembled. Stratnel can design and print dedicated assembly fixtures to help align such sections accurately.

SLA, SLS, and vacuum casting are generally used for smaller components, often around 200 mm, although actual capacity depends on the selected equipment, geometry, and process. Please share your design so that we can confirm feasibility.

Which materials can you print?▾

Stratnel offers a broad range of polymer materials. The appropriate material depends on the application, operating environment, required properties, and manufacturing process. Typical options include:

  • FDM: ULTEM™ 9085, PEEK, PA6-CF, ASA, PETG, ABS, PLA, PC-ABS-FR, and other engineering thermoplastics.
  • SLS: PA12 (Nylon) for rigid parts and TPU 88A for flexible parts.
  • SLA: Standard, tough, clear, and other application-specific photopolymer resins.
  • Vacuum casting: Tough, clear, glass-filled, flexible, and other polyurethane resin systems.

Share your application and performance requirements with Stratnel, and we can recommend a suitable process and material. Relevant material datasheets can also be provided.

What dimensional accuracy and tolerances can you achieve?▾

The achievable accuracy depends on the printing process, material, part geometry, orientation, size, and post-processing requirements. Unless otherwise agreed, our indicative process tolerances are:

ProcessIndicative Tolerance
FDM± 0.5% of nominal dimension or ± 0.3 mm, whichever is greater
SLA, SLS & Vacuum Casting± 0.3% of nominal dimension or ± 0.2 mm, whichever is greater

These are general process guidelines and do not constitute a tolerance commitment for every feature. Please identify all critical dimensions and tolerances in a drawing when requesting a quotation so that Stratnel can review their feasibility and agree on an appropriate inspection plan.

Measurements are typically taken using calibrated vernier callipers and/or a height gauge on a surface plate. Our standard inspection generally covers selected, readily measurable dimensions across the three principal axes; it is not a complete inspection of every dimension in the drawing or CAD model. Full dimensional inspection or inspection of additional characteristics can be arranged when agreed before production.

What is the usual production lead time?▾

Production lead time depends on current machine availability, the size and geometry of the parts, print duration, order quantity, material, post-processing, inspection, and packaging requirements. Finishing processes such as painting may add a few days to the schedule.

We will provide an estimated dispatch date when quoting or confirming your order.
